Ventilation element
Limits condensation in a line with a warm section (interior) and a cold section (exterior) of a building.
Selection of key components
According to the information you have provided, the INNO by Mobilis electrification line should include at least the components displayed and activated. Fill them in in numerical order.
Ventilation element
Limits condensation in a line with a warm section (interior) and a cold section (exterior) of a building.
Limits condensation in a line with a warm section (interior) and a cold section (exterior) of a building.
Part numbers and compatibility
Ordering information
- Only useful if the line has a hot part (inside the workshop) and a cold part (outside the workshop)
- The ventilation element is available in 2 lengths: 1 m and 4 m.
-
Provide 2 sliding hangers, with a center axis distance of 500mm for a 1m element, and of 2m for a 4m element. When you select the quantities of sliding suspensions, you will be reminded of this information.
Part numbers
| Quantity | ||
|---|---|---|
|
40A - Ventilation element, length m |
MI5300 |
|
|
40A - Ventilation element, length 4 m |
MI5340 |
|
|
60A - Ventilation element, length 1m |
MI5301 |
|
|
60A - Ventilation element, length 4 m |
MI5341 |
|
